Desktop Monitor - P2423de Hub Desktop Monitor - 24in - 2560x 1440 At 60 Hz - USB-c

Introduction

Experience pure productivity on a 23.8-inch QHD monitor featuring extensive connectivity and ComfortView Plus.

Display

Display diagonal

60.5 cm (23.8")

Display brightness (typical)

300 cd/m²

Display resolution

2560 x 1440 pixels

Native aspect ratio

16:9

Response time

5 ms

HD type

Quad HD

Display technology

LCD

Backlight type

W-LED

Anti-glare screen

Y

Screen shape

Flat

Supported video modes

480p,576p,720p,1080i,1080p,1440p

Contrast ratio (typical)

1000:1

Maximum refresh rate

60 Hz

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

16.7 million colours

Panel type

IPS

Response time (fast)

8 ms

Pixel pitch

0.2058 x 0.2058 mm

Pixel density

123 ppi

Horizontal scan range

29 - 113 kHz

Vertical scan range

49 - 75 Hz

Viewable size, horizontal

52.7 cm

Viewable size, vertical

29.6 cm

Viewable size diagonal

60.5 cm

Display diagonal (metric)

60.45 cm

sRGB coverage (typical)

99%

Performance

NVIDIA G-SYNC

N

AMD FreeSync

N

Low Blue Light technology

Y

Multimedia

Built-in speaker(s)

N

Built-in camera

N

Design

Market positioning

Home

Product colour

Black, Silver

Front bezel colour

Black

Detachable stand

Y

Feet colour

Silver

Heavy metals free

Hg (mercury)

Ports & interfaces

Built-in USB hub

Y

USB upstream port type

USB Type-C

Number of USB Type-C upstream ports quantity

1

USB Type-A downstream ports quantity

4

USB Type-C DisplayPort Alternate Mode

Y

USB Power Delivery up to

90 W

HDMI

Y

HDMI ports quantity

1

HDMI version

1.4

DisplayPorts quantity

2

DisplayPort version

1.4

Headphone out

N

HDCP

Y

AC (power) in

Y

Ergonomics

Panel mounting interface

100 x 100 mm

Cable lock slot

Y

VESA mounting

Y

Height adjustment

Y

Height adjustment

15 cm

Pivot

Y

Pivot angle

90 - 90°

Swivelling

Y

Swivel angle range

-45 - 45°

Tiltable

Y

Tilt angle range

-5 - 21°

On Screen Display (OSD)

Y

Plug and Play

Y

LED indicators

Y

Power

Energy efficiency class (SDR)

F

Energy consumption (SDR) per 1000 hours

20 kWh

Power consumption (typical)

20 W

Power consumption (standby)

0.3 W

Power consumption (max)

170 W

Power consumption (off)

0.3 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

2 A

Power supply type

Internal

Energy efficiency scale

A to G

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

10 - 80%

Storage relative humidity (H-H)

5 - 90%

Operating altitude

0 - 5000 m

Non-operating altitude

5000 - 12192 m

Sustainability

Sustainability certificates

ENERGY STAR, RoHS, TCO

Doesn't contain

PVC/BFR

Weight & dimensions

Width (with stand)

537.8 mm

Depth (with stand)

179.6 mm

Height (with stand)

496.1 mm

Weight (with stand)

5.55 kg

Width (without stand)

53.8 cm

Depth (without stand)

5.21 cm

Height (without stand)

31.9 cm

Weight (without stand)

3.92 kg

Bezel width (side)

5.48 mm

Bezel width (top)

5.42 mm

Bezel width (bottom)

1.67 cm

Packaging data

Stand included

Y

Cables included

AC, DisplayPort, USB Type-A to USB Type-C, USB Type-C to USB Type-C

Quick start guide

Y

Package weight

7.97 kg

Other features

Ethernet LAN (RJ-45) ports

1
