Vehicle Mount Computer Vm2 802.11abgn Int WLAN Antenna Connections 32GB Flash W7 Etsi

Introduction

Solidifying Honeywell's position as the leader in vehicle-mount computing, the Thor VM2 builds on the best-in-class Thor VM1 that was created specifically to address the unique challenges of supply chain applications.

Ideally suitable for warehouse, port and yard process automation, the Thor VM2 introduces an additional form factor option granting greater flexibility which is emphasized by its 9.7" XGA display, programmable multi-function keys, and WLAN and WWAN connectivity. Available with Microsoft Windows CE 6.0, Windows 7 Pro, Windows Embedded Standard 7 and Windows Embedded Standard 2009 operating systems and compatible with many industry standard terminal emulation and web browser applications including the popular Honeywell RFTermT TE, the Thor VM2 is built for simple and easy application development and system integration.

Ignition Control:
Eliminates the maintenance expense and lost productivity caused by a dead vehicle battery; unit can be configured to automatically go into standby or hibernate at a selectable time after the ignition switch is turned off, saving time for associates while eliminating a point of concern for warehouse management

Smart Dock:
Enables mounting and removal in seconds like a laptop dock but with the ruggedness and sealing required for industrial applications; maximizes efficiency by dynamically shifting workers and computers as he workload changes, while minimizing maintenance cost by enabling a computer to be shifted from one vehicle to another in 1/6 the standard time

Field-Replaceable Front Panel:
Reduces capital and maintenance cost by integrating the two most wear and abuse prone components, the keyboard and touchscreen, into a user-replaceable part; reduces capital costs by
substituting spare front panels for spare computers.

Display

Display diagonal

24.6 cm (9.7")

Display resolution

1024 x 768 pixels

LED backlight

Y

Processor

Processor manufacturer

Intel

Processor family

Intel Atom®

Processor model

Z530

Processor frequency

1.6 GHz

Processor cores

1

Processor threads

2

Processor cache

0.512 MB

Processor front side bus

533 MHz

Bus type

FSB

Conflict-Free processor

N

CPU multiplier (bus/core ratio)

12

FSB Parity

N

Processing Die size

26 mm²

Processor cache type

L2

Processor code

SLB6P

Processor codename

Silverthorne

Processor lithography

45 nm

Processor operating modes

32-bit

Processor package size

13 x 14 mm

Scenario Design Power (SDP)

0.96 W

Stepping

C0

Supported instruction sets

SSE2,SSE3,SSSE3

Tjunction

90 °C

Thermal Design Power (TDP)

2 W

Thermal Monitoring Technologies

Y

Number of Processing Die Transistors

47 M

Memory

Internal memory

2 GB

Internal memory type

SDRAM

Storage

Internal storage capacity

32 GB

Card reader integrated

Y

Compatible memory cards

SD

Storage media

Flash

Graphics

Graphics card family

Intel

Graphics card

GMA 500

Audio

Built-in speaker(s)

Y

Built-in microphone

Y

Camera

Rear camera

N

Video recording

N

Front camera

N

Network

Bluetooth

N

Top Wi-Fi standard

Wi-Fi 4 (802.11n)

Wi-Fi standards

802.11a,802.11b,802.11g,802.11n

Ports & interfaces

USB 2.0 ports quantity

1

Headphone out

Y

Design

Form factor

Slate

Product colour

Grey, Silver

Performance

GPS (satellite)

N

Position location

N

Software

Operating system installed

Windows 7 Pro

Processor special features

Intel® Turbo Boost Technology

N

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Enhanced Intel SpeedStep Technology

Y

Embedded options available

Y

Execute Disable Bit

Y

Idle States

Y

Intel 64

N

Intel Enhanced Halt State

Y

Intel Trusted Execution Technology

N

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

N

Intel Demand Based Switching

Y

Battery

Battery technology

Lithium-Ion (Li-Ion)

Weight & dimensions

Width

268 mm

Depth

53 mm

Height

214 mm

Weight

2.2 kg

Packaging content

Keyboard included

N

Features

Images Type Map

Operational conditions

Operating temperature (T-T)

-20 - 50 °C

Storage temperature (T-T)

-20 - 50 °C

Other features

Processor socket

PBGA441

Speakers

stereo

Wi-Fi

Y

Processor ARK ID

35463
