Xeon Processor W-2135 3.70GHz 8.25MB Cache

Introduction

Intel® Transactional Synchronization Extensions New Instructions (Intel® TSX-NI) are a set of instructions focused on multi-threaded performance scaling. This technology helps make parallel operations more efficient via improved control of locks in software.

Intel® Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel® IPT provides a hardware-based proof of a unique user’s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel® IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.

Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Processor

Processor manufacturer

Intel

Processor model

W-2135

Processor base frequency

3.7 GHz

Processor family

Intel® Xeon®

Processor cores

6

Processor socket

LGA 2066 (Socket R4)

Component for

Server/workstation

Processor lithography

14 nm

Processor threads

12

System bus rate

8 GT/s

Processor operating modes

64-bit

Processor boost frequency

4.5 GHz

Processor cache

8.25 MB

Thermal Design Power (TDP)

140 W

Box

Y

Cooler included

Y

Stepping

U0

Bus type

QPI

Memory bandwidth supported by processor (max)

85.3 GB/s

Processor codename

Skylake

Processor code

SR3LN

Processor ARK ID

126709

Memory

Maximum internal memory supported by processor

512 GB

Memory types supported by processor

DDR4-SDRAM

Memory clock speeds supported by processor

1600,1866,2133,2400,2666 MHz

Memory channels

Quad-channel

ECC

Y

Graphics

On-board graphics card

N

Features

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Market segment

Server

Maximum number of PCI Express lanes

48

PCI Express slots version

3.0

PCI Express configurations

1x16,1x4,1x8

Supported instruction sets

SSE4.2,AVX,AVX 2.0,AVX-512

Scalability

1S

Physical Address Extension (PAE)

Y

CPU configuration (max)

1

Embedded options available

N

Physical Address Extension (PAE)

46 bit

PCI Express CEM revision

3.0

Harmonized System (HS) code

8542310001

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

G077159

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Intel® Identity Protection Technology (Intel® IPT)

Y

Intel® Turbo Boost Technology

2.0

Intel Flex Memory Access

N

Intel® AES New Instructions (Intel® AES-NI)

Y

Enhanced Intel SpeedStep Technology

Y

Intel Trusted Execution Technology

Y

Intel® Memory Protection Extensions (Intel® MPX)

Y

Intel® Device Protection Technology (Intel® DPT) with Boot Guard

Y

Intel® Speed Shift Technology

Y

Intel® Transactional Synchronization Extensions

Y

Intel Enhanced Halt State

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Intel Demand Based Switching

Y

Intel® Secure Key

Y

Intel TSX-NI

Y

Intel® OS Guard

Y

Intel Software Guard Extensions (Intel SGX)

N

Intel 64

Y

Intel Identity Protection Technology version

1.00

Intel Secure Key Technology version

1.00

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel TSX-NI version

1.00

Conflict-Free processor

Y

Intel Turbo Boost Max Technology 3.0

N

Intel® Optane™ Memory Ready

N

AVX-512 Fused Multiply-Add (FMA) units

2

Intel® Boot Guard

Y

Intel® Volume Management Device (VMD)

Y

Intel® vPro™ Platform Eligibility

Y

Operational conditions

Tcase

64 °C

Technical details

Bus type units

GT/s

Launch date

Q3'17

Processor cache

8448 KB

Product type

Processor

Status

Launched

Maximum memory

512 GB

Processor brand name

Intel Xeon

Supported memory types

DDR4-SDRAM

Last change

63903513

Product family

Intel Xeon Processors

Intel® Speed Shift Technology version

1.00

Intel® Volume Management Device (VMD) version

1.00

Bus speed

8 GT/s

Packaging data

Package type

Retail box

Weight & dimensions

Processor package size

45mm x 52.5mm

Other features

Maximum internal memory

512 GB

Maximum internal memory

524288 MB
