Data Protection Dp340 Activeprotect Appliance

Introduction

Cyber-resilient Data Protection
Solution for Endpoints
The Synology ActiveProtect appliance DP340 is a data protection solution that comes preconfigured with hardware that runs ActiveProtect Manager, an operating system designed specifically for backup purposes. With its ability to perform backups, restore, deduplicate, replicate, and manage while ensuring security, the DP340 is an ideal backup server for your small and medium endpoints. It seamlessly integrates all current and future workloads across multiple sites into clusters, enabling centralized management through a single platform. With immutability, air-gapped backups, and access control, the DP340 protects against ransomware attacks, and secures all your data.

Quick and seamless deployment
Essential configuration such as disk partitioning and raid array setup will be automatically completed, making deployment fast and effortless so that you can start protecting your data immediately.

Protect workloads with specified policies
Safeguard all your workloads, including VMware vSphere, Microsoft Hyper-V, Windows, macOS, Linux, NetApp ONTAP, Nutanix Files, Microsoft 365 services, Oracle Database, and Microsoft SQL server. Establish policies for companies to meet SLA requirements, and automate data protection by detecting existing and future workloads, ensuring that the workloads are secured under the appropriate policies. View, modify, and manage policies with ease.

Reliable backup and flexible recovery
The DP340 supports self-healing functionality with continuous detection of silent data corruption through Btrfs checksum. It ensures zero errors by repairing corrupt data via RAID technology. To verify the recoverability of backup data, disaster recovery drills can be regularly performed in a sandboxed environment without affecting your primary production site. Backup verification is also available, automatically generating recovery drill videos for auditing purposes. In the event of a disaster, data can be flexibly restored based on your Recovery Time Objectives (RTO) via entire machine restoration, file-level recovery, physical-to-virtual (P2V), or virtual-to-virtual (V2V) methods to restore data to the designated location.

Uncompromised ransomware protection
To prevent ransomware attacks, the DP340 protects data backups and backup copies with immutability and write-once-read-many (WORM) storage to ensure that no one can modify data that has been backed up during the specified retention period. Additionally, it integrates encryption capabilities, enabling data to be encrypted locally before being backed up to remote destinations. To further enhance security, you can also isolate the remote environment using the air-gap feature.

Optimized backup efficiency
The DP340 optimizes storage space allocation via hardware and software integration. By leveraging SSD cache to store backup-related metadata, optimizing data organization, and consolidating multiple files into a single image, it accelerates data processing. Both backups and backup copies utilize global source-side deduplication, as it compares data at the source and only transmits non-duplicate data to save bandwidth and storage space.

Data security at its core
The DP340's security mechanism is based on the principle of least-privilege authentication and network protection architecture. This mechanism only allows authorized personnel to access data, restricts access to specific devices, and limits access to the backup infrastructure during designated times to ensure data security.
• For authorized personnel: Active Directory, LDAP, and SAML 2.0 integration enables enterprises to use existing SSO with MFA and granular permissions to enhance access control.
• For devices: Firewall settings can be configured to only allow access from devices within specified IP ranges and subnets. The built-in management port is an isolated interface dedicated for management purposes. It is separate from data flow to reduce security risks.
• Enhanced isolation: Secure your remote backup infrastructure via air-gapped solutions to achieve network or physical isolation. Limit network access to specified times or turn your devices on or off.

Storage

Storage drive interface

Serial ATA

Maximum supported storage capacity

14.5 TB

RAID support

Yes

Storage drives installed

No

Number of storage drives supported

4

Installed storage drive type

No

Supported storage drive types

HDD & SSD

Processor

Processor manufacturer

AMD

Processor model

R1600

Memory

Internal memory

16 GB

Network

Ethernet LAN

Yes

Ethernet LAN data rate supported (max)

10000 Mbit/s

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1

Ethernet LAN (RJ-45) ports

2

Design

Chassis type

Desktop

Cooling type

Active

Product colour

Black

Number of fans

2 fan(s)

Drive bay locking

Yes

LED indicators

Status

Cable lock slot

Yes

Cable lock slot type

Kensington

Performance

Type

NAS

Backup function

Yes

Reset button

Yes

Power

Power consumption (typical)

35.51 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Weight & dimensions

Width

19 mm

Depth

223 mm

Height

166 mm

Weight

5.2 kg

Packaging content

External power adapter

Yes

Cables included

AC, LAN (RJ-45)

Operational conditions

Operating temperature (T-T)

0 - 45 °C

Operating relative humidity (H-H)

8 - 80%

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

5 - 95%
