Unit Level Ec 0u Input Iec 60309

Introduction

The Vertiv Geist Unit Level Monitored Rack PDU VP4G9000 is a 32A, 230V, 0U vertical rack power distribution unit (rPDU) with 36 Combination C13/C19 outlets, and a 1P+N+E plug providing 7.3kW in power capacity. This Monitored PDU has residual current metering (RCM-B) that monitors insulation level within the IT rack and alerts users of fault conditions requiring immediate action to prevent potential life-threatening injuries, or a complete system shutdown. The rPDU also has a hot-swappable Interchangeable Monitoring Device (IMD) that displays current on the local LED display. The IMD includes ports for serial communication, environmental monitoring, and dual ethernet port. Simplify management of multiple PDUs with fault-tolerant daisy chaining or IP aggregation capabilities. This CE marked PDU meets an important requirement for data centers and each unit undergoes individual testing for functionality to help ensure your network is powered by a reliable rPDU.

Design

PDU types

Monitored

Type

Three-phase

Rack capacity

0U

Mounting

Vertical

Display

LED

Ports & interfaces

AC outlets quantity

36 AC outlet(s)

AC outlet types

C13 coupler, C19 coupler

Features

Cable length

3 m

Certification

CE Marked

Management features

Monitoring

Current

Management protocols

DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+

Power

Nominal input voltage

230 V

Maximum current

32 A

Output voltage

230 V

Power protection features

Over current

Weight & dimensions

Width

51 mm

Depth

51 mm

Height

1683 mm

Weight

7.26 kg

Packaging data

Package weight

7.62 kg

Package width

230 mm

Package depth

1829 mm

Package height

153 mm

Logistics data

Country of origin

United Kingdom
