Core i7 Processor I7-13700 2.10 GHz 30MB Smart Cache

Introduction

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Processor

Processor manufacturer

Intel

Processor generation

13th gen Intel® Core™ i7

Processor model

i7-13700

Processor family

Intel® Core™ i7

Processor cores

16

Processor socket

LGA 1700

Processor threads

24

Processor operating modes

64-bit

Performance cores

8

Efficient cores

8

Processor boost frequency

5.2 GHz

Performance-core boost frequency

5.1 GHz

Performance-core base frequency

2.1 GHz

Efficient-core boost frequency

4.1 GHz

Efficient-core base frequency

1.5 GHz

Processor cache

30 MB

Processor cache type

Smart Cache

Box

Y

Processor base power

65 W

Maximum turbo power

219 W

Maximum number of DMI lanes

8

Processor codename

Raptor Lake

Processor ARK ID

230490

Memory

Maximum internal memory supported by processor

128 GB

Memory types supported by processor

DDR4-SDRAM, DDR5-SDRAM

Memory channels

Dual-channel

ECC

Y

Memory bandwidth (max)

89.6 GB/s

Graphics

On-board graphics card

Y

Discrete graphics card

N

On-board graphics card model

Intel UHD Graphics 770

On-board graphics card outputs supported

Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1

On-board graphics card base frequency

300 MHz

On-board graphics card dynamic frequency (max)

1600 MHz

Number of displays supported (on-board graphics)

4

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card maximum resolution (DisplayPort)

7680 x 4320 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

120 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card ID

0xA780

Discrete graphics card model

Not available

Number of execution units

32

Multi-Format Codec Engines

2

Features

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Market segment

Desktop

Use conditions

Workstation, PC/Client/Tablet

Maximum number of PCI Express lanes

20

PCI Express slots version

4.0, 5.0

PCI Express configurations

1x16+1x4, 2x8+1x4

Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2

Scalability

1S

CPU configuration (max)

1

Embedded options available

Y

Direct Media Interface (DMI) Revision

4.0

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

740.17B1

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Intel® Turbo Boost Technology

2.0

Intel® Quick Sync Video Technology

Y

Intel® Clear Video HD Technology (Intel® CVT HD)

Y

Intel® AES New Instructions (Intel® AES-NI)

Y

Enhanced Intel SpeedStep Technology

Y

Intel Trusted Execution Technology

Y

Intel® Speed Shift Technology

Y

Intel® Turbo Boost Max Technology 3.0 frequency

5.2 GHz

Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0

Y

Intel® Control-flow Enforcement Technology (CET)

Y

Intel® Thread Director

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Intel® Secure Key

Y

Intel® OS Guard

Y

Intel 64

Y

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel Turbo Boost Max Technology 3.0

Y

Intel® Boot Guard

Y

Intel® Deep Learning Boost (Intel® DL Boost)

Y

Intel® Volume Management Device (VMD)

Y

Mode-based Execute Control (MBE)

Y

Intel® Standard Manageability (ISM)

Y

Operational conditions

Tjunction

100 °C

Technical details

OpenCL version

3.0

Launch date

Q1'23

Logistics data

Harmonized System (HS) code

8542310001

Weight & dimensions

Processor package size

45 x 37.5 mm

Other features

L2 cache

24576 KB

Graphics output

eDP 1.4b, DP 1.4a, HDMI 2.1
